This is a set of development kit and 5.83 inch colorful e-ink display with 648x480 resolution, 24 pins FPC connection, optional FPC connector, communicating via SPI interface, with embedded controller(COG package) and on-chip stored waveform. The display resolution is higher than GDEW0583Z21(600x448).
DESPI Develop Kit consists of the development board DESPI-M02 and the pinboard DESPI-C02.
It supports driving Good Display's black-white E-paper Display and three-color (black, white and red/Yellow) E-paper Display.

· Higher resoluiton(648x480) than GDEW0583Z21(600x448).
· Keep displaying the last content when power down.
· Ultra low power consumption, basically power is only required for refreshing.
· USB serial port, Raspberry Pi and LED indicator light.
· Come with helpful development demo kit with resources and manual (STM32 platform )

1. Driving board DESPI-M02 *1pc
2. Connector board DESPI-C02 *1pc
3. USB port cable *1pc
4. 5.83 inch color e-ink display 648x480 high resolution electronic paper screen*1pc
5. Matched FPC Connector*1pc
6 .Helpful resources and manual(sent via email or download link) *1pc
If you only want to buy this e-paper display, click here:
http://upaj177.myueeshop.com/583-inch-high-resolution-color-red-e-paper-display-tri-color-e-ink-screen-module-buy-gdew0583z83-p0263.html
Part Number |
GDEW0583Z83 |
Type |
Dot Matrix |
Resolution |
640(H)*480(V) |
Outline Size(mm) |
125.40x99.50x1.18 |
Actve Size(mm) |
119.232x88.320 |
Pixel Pitch(mm) |
0.184x0.1874 |
Operating Temp. |
0~40C |
Storage Temp. |
-25~60C |
Max Grayscale |
2 |
Color |
Black, White, Red |
Interface |
SPI |
Power Supply | 3.3V |
Part Number |
DESPI |
Platform |
STM32 |
Function |
Drive E-paper Display |
Outside Dimension |
90x60mm (DESPI-M02) |
Power Interface |
USB Interface |
Power Input |
DC5V |
Feature |
Fully and Partial refresh |
Grey scale Level |
Max 16 grey scale |
Operating Temp |
-20~70℃ |
Recommended Tool |
Keil4 |
Example Code |
Available |
Reserved Function |
USB to serial port, indicator |
Part Number |
Color |
Features |
Refresh Time | T/P(optional) | Front-Light (optional) |
B/W |
SPI interface |
3S | -- |
-- |
|
B/W/R |
Three colors |
15S | -- |
-- |
|
GDEW0583Z83 | B/W/R | Three colors,high resolution | -- | -- | -- |
B/W/Y |
Three colors |
25S | -- |
-- |
