E-Ink Paper Front-Light Touch 2.7" e-Paper Display for Raspberry Pi Eink Display Module HAT Starter Kit

GDEY027T91-FT11
A compact 2.7-inch E-Ink display with 264x176 resolution, front light, fast refresh rates, and touchscreen functionality—perfect for low-power, portable, and interactive devices.
1 Review(s) Sold:7
Have a question?
Price:
USD
$13.86
  • Product:
    EPD
    EPD with adapter board
    EPD with STM32 adapter board
    EPD with STM32 Demo Kit
    EPD with ESP32 adapter board
    EPD with ESP32 Demo Kit
    STM32 adapter board
Quantity:
-
+
(30 available)
Shipping Cost:
to
Estimated Delivery Time:
Please select the country you want to ship from
Please select the information you wantX
Inquiry Now
Add to Favorite Items
  • Description
  • Reviews(1)


Eye-Friendly 2.7inch E-Ink Carta™ HD Touchscreen with Front-Light





Meet the ultimate fusion of technology and convenience: a 2.7-inch E-Ink display designed for modern, low-power applications. With a sharp 264x176 resolution, lightning-fast refresh rates , and a built-in front light, it delivers brilliant performance day or night. The best part? It holds its image indefinitely without using power after an update. Add touchscreen functionality, and you’ve got a sleek, intuitive display that’s ready to elevate smart devices, wearables, and more. Compact, efficient, and endlessly versatile, it’s your go-to screen for every innovative project.



TIP: The front light & touch screen is not sold separately due to precise bonding requirements. Please purchase the complete bonded product. For temperature details, refer to the display screen specifications.











Special Features


  ● Front Light, Read Anytime – Built-in lighting for clear visibility in low light, read effortlessly day or night.
  ● Touch Control, Intuitive & Smooth – Precise touch response, swipe and tap with ease for seamless navigation.
  ● 2.7-inch Display with Fast Refresh, achieve maximum efficiency with a 1.5 s full refresh and a super-fast 0.3 s partial refresh.
  ● A wide range of development solutions, dedicated after-sales support, and comprehensive user manuals to ensure your success every step of the way.






Touch in the Dark, Light Always with You

— The Perfect Fusion of Front Light and Touchscreen


GDEY0213B74-FT11

The GDEY027T91-FT11 is a 2.7-inch E Ink display featuring  front light and touch screen functionality, with a resolution of 264x176, power consumption of the refresh 12 mW. It offers impressive refresh rates, ensuring smooth and efficient performance for various applications.

This e-paper display is built on the standard 2.7-inch model（GDEY027T91）, enhanced with a front light and touchscreen functionality. The front light can even flash in low-light conditions, serving as a warning feature. With the integrated touchscreen, users can interact directly with the display, significantly improving usability. It's ideal for embedded control systems, intuitive input devices, interactive displays, especially in low-light environments.（This video is for demonstration purposes only and does not represent the actual product.）






Technical Details










Product Specifications


PART NUMBER GDEY027T91-FT11 TOUCH CONNECTOR 6 Pin FPC
TYPE Dot Matrix TOUCH IC FT6336U
SIZE 2.7 inch TOUCH VOLTAGE 2.8-3.6 V
IC SSD1680Z8 FRONT-LIT CONNECTOR 6 pin FPC
RESOLUTION 264x176 NUMBER OF LED LIGHT 4
OUTLINE SIZE(mm) 70.42x45.8x2.1 FRONT-LIT CIRCUIT MODE Series connection
ACTIVE SIZE(mm) 57.29x38.19 OPERATING VOLTAGE 2.8V-3.3V
ACTIVE SIZE(mm) 0.217x0.217 OPERATING CURRENT ≤60mA
OPERATING TEMP. 0℃~50℃ FULL REFRESH(s) 2
STORAGE TEMP. -25℃~70℃ FAST REFRESH(s) 1.5
CONNECTOR 24 Pin FPC PARTIAL REFRESH TIME(s) 0.3
MAX GRAYSCALE 4 POWER CONSUMPTION OF THE REFRESH(mW) 12
COLOR Black,White STANDBY POWER CONSUMPTION (mW) 0.003
INTERFACE SPI










Matching Driver Boards





Ⅱ. DESPI-F01
(Front-light Driver Board)

Ⅲ. STM32-T01
(STM32 adapter Board)

Ⅳ. DESPI-L(T01)
(STM32 Demo Kit)

Ⅴ. ESP32-T01
(ESP32 adapter Board)

Ⅵ. ESP32-L(T01)
(ESP32 Demo Kit)











Files And Download


● GDEY027T91-FT11_Specification ● Why can't I download the files(updated)?
● The Lastest Catalog







Product Application

Smart Home Control Panels

 Portable Health Devices

Industrial Control Terminals

Nameplates and Desk Cards

Personalized Accessories









Every Day is Earth Day




  You don't need to be an environmental scientist to make sustainable choices.
At GooDisplay, we passionately integrate sustainability into the production of e-paper.









Substitute for Paper Usage

Epaper provide a paper-like touch and reading experience, serving as a sustainable alternative to traditional paper and reducing environmental impact from deforestation and paper manufacturing.

Device Packaging
95% of this device's packaging is crafted from wood fiber-based materials sourced responsibly from managed forests or recycled sources.

Energy Efficiency
Epaper consumes minimal energy compared to conventional displays, reducing electricity bills and easing the demand on power plants, thereby lowering greenhouse gas emissions—a perfect choice for eco-conscious consumers.











ABOUT US
Thank you for your interest in our product. We could provide front light, touch screen, and other accessories for you. For more information, please refer to the relevant manual available in our Library or visit our official website at [www.good-display.com].
If you need any further assistance or have any other questions, please feel free to contact us. We sincerely invite you to send your inquiries to our email at [buyepaper@good-display.com].
