2.9 inch e-paper display with frontlight backlit partial refresh E-ink GDEW029T5D-FL02

This is an E ink E paper display panel with frontlight backlit, 2.9 inch, 296x128 resolution, 24 pins FPC connection, optional FPC connector, communicating via SPI interface, 4 Grayscale,  supports black and white.
    Please select the information you wantX
  • 规格:
    With adapter board
    With demo kit
(0 available)
  • Description
  • Size Chart
  • Measurement
  • Color Chart
  • Reviews

Any questions, please feel free to contact me, my email is:

This is an E ink E paper display panel with frontlight, 2.9 inch, 296x128 resolution, support partial and 4 Grayscale, 24 pins FPC connection, optional FPC connector, communicating via SPI interface, with embedded controller(COG package) and on-chip stored waveform,  supports black and white. It's IC Driver is UC8151D.

In view of so many advantages: ultra low power consumption, near 180 degree view angle, readable under sunlight, GDEW029T5D-FL02 is a very good choice for applications like shelf label, smart tags, smart home application, industrial instrument, smart cards and other related products.

· With frontlight backlit
· Support partial refresh.
· 4 Grayscale
· 296x128 resolution
· The I2C signal master interface to read built-in temperature sensor.
· Come with helpful development resources and manual
· Development platform available
STM32 / Arduino Raspberry Pi / ESP8266 / ESP32

1. 2.9 inch e-paper e-ink screen with frontlight GDEW029T5D-FL02 *1pc
2. Matched FPC Connector*2pcs
3.Helpful resources and manual(sent via email or download link) *1pc
Part Number GDEW029T5D-FL02
Size 2.9 inch
Type Dot Matrix
IC UC8151D
Resolution 296x128
Outline Size(mm) 79x36.7x2.3
Active Size(mm) 66.9x29.06
Pixel Pitch(mm) 0.227x0.226
Operating Temp. 0℃~50℃
Storage Temp. -25℃~70℃
Number of LEDs 4
Max Grayscale 4
Time of refresh(s) 3
Time of partial refresh(s) 0.3
Interface SPI

Part Number



Refresh Time
GDEM029T94 B/W Partial refresh, 4 Grayscale 3S
GDEW029M06 B/W DES,Extended working temperature -20℃~+60℃, can be used in sunlight and cold environments, Partial refresh 3S


SPI interface




Fast refresh, Partial refresh, 4 Grayscale

0.82S(fast refresh)



Ultra-low temperature




Flexible, Partial refresh, 4 Grayscale


GDEH029Z92 B/W/R Three colors 13S
GDEH029Z13 B/W/R Three colors 15S
