This is a 7.5 inch colorful e-ink display with 800x480 resolution, 24 pins FPC connection, optional FPC connector, communicating via SPI interface, with embedded controller(COG package) and on-chip stored waveform. The display resolution is higher than GDEW075C21(640x384).
In view of so many advantages: ultra low power consumption, near 180 degree view angle, readable under sunlight, GDEW075C64 is a very good choice for applications like shelf label, smart home application, industrial instrument, electronic conference table card and other related products.

· Higher resoluiton(800x480) than GDEW075C21(640x384).
· Tri-color: black, whtie and yellow.
· Ultra low power consumption, basically power is only required for refreshing.
· SPI interface, for connecting with controller boards
· Come with helpful development resources and manual (STM32 platform )

1)7.5 inch colorful e-paper display 800x480 GDEW075C64 *1pc
2) Matched FPC Connector*1pc
3) Example code and Manual*1pc.(Please advise email ID along with order,so that we can send them.)

Part Number |
GDEW075C64 |
Type |
Dot Matrix |
Resolution |
800x480 |
Outline Size(mm) |
170.2*111.2*1.18 |
Actve Size(mm) |
163.2*97.92 |
Pixel Pitch(mm) |
0.205x0.204 |
Operating Temp. |
0~40C |
Storage Temp. |
-25~60C |
Connector |
24 Pin FPC, Pitch:0.5mm |
Color |
Black,White,Yellow |
Interface |
SPI |
Power Supply | 3.3V |
Part Number |
Color |
Resolution |
Features |
Refresh Time |
B/W |
640*384 |
Large size |
4S |
|
B/W/Y |
640*384 |
Colorful |
18S |
|
GDEW075C64 | B/W/Y | 800*480 |
Higher resolution, Colorful |
-- |
GDEW075Z09 | B/W/R |
640*384 |
Colorful |
16S |
B/W |
800*480 |
Higher resolution, 4 Grayscale |
4S |
|
B/W/R |
800*480 |
Higher resolution, Colorful |
15S |

Visit Following link to order the Demo that matched with this e-paper:

http://www.e-paper-display.com/products_detail/productId=465.html
